Overview
The Caterpillar 160H ES is a motor grader listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include fuel capacity of 90.1 gal and hydraulic capacity of 21.2 gal. This model can be reviewed for equipment comparison, jobsite planning, fleet research, and specification-based machine selection. Use the full specifications table to compare the Caterpillar 160H ES against similar motor grader models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Std Operation Weight - Total
34,361.30
lb
Max Power
200
hp
Moldboard Width
23.90
ft
Overall Length
28.22
ft
Full Specifications
30 specs
Dimensions
Blade Base
8.27 in / 210 mm
Height To Top Of Isomount Cab
10.24 ft / 3.12 m
Overall Length
28.22 ft / 8.60 m
Wheelbase
19.99 ft / 6.09 m
Width Over Tires
8.14 ft / 2.48 m
Engine
Alternator Supplied Amperage
50 A
Articulation Angle
20 deg
Displacement
638 cu in / 10.5 L
Engine Make
2236
Engine Model
3306 DITA
Fuel Capacity
90.10 gal / 341.1 L
Hydraulic System Fluid Capacity
21.20 gal / 80.3 L
Max Power
200 hp / 149.1 kW
Max Speed - Forward
25.30 mph / 40.7 km/h
Max Speed - Reverse
20 mph / 32.2 km/h
Moldboard Height
27.10 in / 688 mm
Moldboard Thickness
1 in / 25 mm
Moldboard Width
23.90 ft / 7.28 m
Net Power Gear 4-6
180 hp / 134.2 kW
Net Power Gears 7-8
200 hp / 149.1 kW
Number Of Gears - Forward
8
Number Of Gears - Reverse
6
Operating Voltage
24 V
Oscillation - Total
32 deg
Pump Flow
54.50 gal/min / 206.3 L/min
Relief Valve Pressure
3,500 psi / 241.3 bar
Std Operation Weight - Total
34,361 lb / 15,586 kg
Turning Radius
24.30 ft / 7.41 m
Wheel Lean
18 deg
Hydraulics
Max Lift Above Ground
17.80 in / 452 mm
Videos 1
