Overview
The Caterpillar 365C FS Shovel is a shovel listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 411 hp, travel speed of 2.6 mph, fuel capacity of 211.4 gal and hydraulic capacity of 177.0 gal. This model can be reviewed for equipment comparison, jobsite planning, fleet research, and specification-based machine selection. Use the full specifications table to compare the Caterpillar 365C FS Shovel against similar shovel models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Net Power
411
hp
Full Specifications
26 specs
Dimensions
Ground Clearance
2.76 ft / 0.84 m
Height to Top of Cab
15 ft / 4.57 m
Length Of Tracks
19.23 ft / 5.86 m
Tail Swing Radius
13.19 ft / 4.02 m
Upper Structure Ground Clearance
5.06 ft / 1.54 m
Width Over Tracks
12.80 ft / 3.90 m
Engine
Alternator Supplied Amperage
75 A
Cooling System Fluid Capacity
25.10 gal / 95.0 L
Displacement
928 cu in / 15.2 L
Engine Make
2236
Engine Model
C15 Diesel engine with ACERT techonlogy
Engine Oil Capacity
14.30 gal / 54.1 L
Fuel Capacity
211.40 gal / 800.2 L
Hydraulic System Fluid Capacity
177 gal / 670.0 L
Net Power
411 hp / 306.5 kW
Power Measured @
1,800 rpm
Swing Speed
6.50 deg
Undercarriage
Backhoe Operating Weight - Shoe 1
163,803 lb / 74,300 kg
Backhoe Shoe Width 1
25.60 ft / 7.80 m
Backhoe Shoe Width 2
24.02 ft / 7.32 m
Backhoe Shoe Width 3
29.53 ft / 9.00 m
Max Travel Speed
2.55 mph / 4.1 km/h
Number Of Lower Rollers
8
Number Of Track Shoes Per Side
47
Number Of Upper Rollers
3
Track Gauge
10.67 ft / 3.25 m
Videos 14
Related Machines
Frequently Asked Questions
How powerful is the Caterpillar 365C FS Shovel engine? +
The Caterpillar 365C FS Shovel produces 411 hp (306.5 kW) of engine power. This output is typical for its weight class and designed to handle demanding Shovel work cycles efficiently.
What is the travel speed of the Caterpillar 365C FS Shovel? +
The Caterpillar 365C FS Shovel has a maximum travel speed of 2.6 mph (4.1 km/h), enabling efficient movement between work areas on the job site.
How does the Caterpillar 365C FS Shovel compare to similar Shovel models? +
You can compare the Caterpillar 365C FS Shovel side by side with any other model using the Heavy Equipment Hub compare tool. Key comparison points include engine power, operating weight, digging depth, hydraulic flow, and overall dimensions.
