Overview
The Caterpillar TH340B Telescopic is a forklift listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 95 hp, operating weight of 16,976 lb, fuel capacity of 30.4 gal and hydraulic capacity of 15.9 gal. This model can be reviewed for lifting capacity, load handling, warehouse use, yard work, and material handling comparison. Use the full specifications table to compare the Caterpillar TH340B Telescopic against similar forklift models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Operating Weight
16,975.60
lb
Net Power
94.90
hp
Gross Power
99.90
hp
Max Lift Capacity
7,275.30
lb
Full Specifications
70 specs
Dimensions
Ground Clearance
1.60 ft / 0.49 m
Length - Fork Face
16.20 ft / 4.94 m
Length To Fork Face
16.25 ft / 4.95 m
Max Forward Reach
21.33 ft / 6.50 m
Max Lift Capacity
6,614 lb / 3,000 kg
Max Lift Height
29.53 ft / 9.00 m
Max Load At Max Height
4,409.25 in / 111,995 mm
Max Load At Max Reach
1,323 lb / 600 kg
Overall Height
7.91 ft / 2.41 m
Turning Radius - Over Forks
15.40 ft / 4.69 m
Turning Radius - Over Tires
12.30 ft / 3.75 m
Turning Radius Outside Tires
12.31 ft / 3.75 m
Wheel Base
10 in / 254 mm
Wheelbase
10.01 ft / 3.05 m
Width Over Tires
8.18 ft / 2.49 m
Engine
Alternator Supplied Amperage
105 A
Bore
4 in / 102 mm
Displacement
268 cu in / 4.4 L
Engine Make
2236
Engine Model
3054E
Forward - 1
3.80 mph / 6.1 km/h
Forward - 2
7.50 mph / 12.1 km/h
Forward - 3
12.50 mph / 20.1 km/h
Forward - 4
19.90 mph / 32.0 km/h
Fuel Capacity
30.40 gal / 115.1 L
Fuel Tank
29.90 gal / 113.2 L
Gross Power
100 hp / 74.5 kW
Height
7.90 ft / 2.41 m
Hydraulic System Fluid Capacity
15.90 gal / 60.2 L
Hydraulic Tank
15.60 gal / 59.1 L
Max Speed - Forward
19.90 mph / 32.0 km/h
Max Speed - Reverse
12.50 mph / 20.1 km/h
Max Torque
303 lb-ft / 410 Nm
Maximum Torque
303 lb-ft / 411 Nm
Net Power
95 hp / 70.8 kW
Number of Forward Gears
4
Number of Reverse Gears
3
Operating Voltage
12 V
Operating Weight
16,976 lb / 7,700 kg
Power Measured @
2,200 rpm
Relief Valve Pressure
3,626 psi / 250.0 bar
Reverse - 1
3.80 mph / 6.1 km/h
Reverse - 2
7.50 mph / 12.1 km/h
Reverse - 3
12.50 mph / 20.1 km/h
Standard
13.00-24
Stroke
5 in / 127 mm
Tire Size
13 in / 330 mm
Torque Measured @
1,400 rpm
Width
8.20 ft / 2.50 m
Hydraulics
Auxiliary Hydraulic Supply - Continuous
15.60 gal/min / 59.1 L/min
Auxiliary Hydraulic Supply - Intermittent
23.40 gal/min / 88.6 L/min
Maximum Pump Flow
29.40 gal/min / 111.3 L/min
Maximum System Pressure
3,625 psi / 249.9 bar
Pump Flow Capacity
29.90 gal/min / 113.2 L/min
Other
Load At Maximum Height
4,400 in / 111,760 mm
Load At Maximum Reach
1,320 lb / 599 kg
Maximum Forward Reach
21.30 ft / 6.49 m
Maximum Lift Height
30 ft / 9.14 m
Rated Load Capacity
6,600 lb / 2,994 kg
Top Travel Speed
20 mph / 32.2 km/h
Boom Down
6
Boom Up
8
Combined - Down And In
16
Combined - Up And Out
16
Crowd Backward
3
Crowd Forward - Dump
3
Max Lift Capacity
7,275 lb / 3,300 kg
Tele In
10
Tele Out
8
Transmission Speeds
4
Videos 1
Related Machines
Frequently Asked Questions
What is the operating weight of the Caterpillar TH340B Telescopic? +
The Caterpillar TH340B Telescopic has an operating weight of 16,976 lb (7,700 kg). This places it in a class suited for forklift applications where ground pressure and transport weight are key considerations.
How powerful is the Caterpillar TH340B Telescopic engine? +
The Caterpillar TH340B Telescopic produces 100 hp (74.5 kW) of engine power. This output is typical for its weight class and designed to handle demanding Forklift work cycles efficiently.
How does the Caterpillar TH340B Telescopic compare to similar Forklift models? +
You can compare the Caterpillar TH340B Telescopic side by side with any other model using the Heavy Equipment Hub compare tool. Key comparison points include engine power, operating weight, digging depth, hydraulic flow, and overall dimensions.
