Overview
The Caterpillar 992K is a wheel loader listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 801 hp, operating weight of 214,948 lb and fuel capacity of 413.0 gal. This model can be reviewed for loading, stockpile work, material handling, yard operations, and fleet comparison workflows. Use the full specifications table to compare the Caterpillar 992K against similar wheel loader models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Operating Weight
214,948
lb
Net Power
801
hp
Gross Power
880
hp
Bucket Capacity - Heaped
15
yd3
Full Specifications
145 specs
Dimensions
Breakout Force
128,895 lb / 58,466 kg
Bucket Capacity - Heaped
16 yd³ / 12.23 m³
Bucket Capacity - Struck
14 yd³ / 10.70 m³
Bucket Width
15.83 ft / 4.82 m
Bumper Clearance
3.86 ft / 1.18 m
Dump Clearance At Max Raise
15.12 ft / 4.61 m
Ground Clearance
2.25 ft / 0.69 m
Height - Top Of Hood
17.22 ft / 5.25 m
Height - Top Of Rops/Fops
18.63 ft / 5.68 m
Height to Top of Cab
18.63 ft / 5.68 m
Length With Bucket On Ground
51.63 in / 1,311 mm
Reach At Max Lift And Dump
7.64 ft / 2.33 m
Tread Width
10.90 ft / 3.32 m
Wheel Base
19.40 in / 493 mm
Wheel Base Length
19.32 ft / 5.89 m
Wheelbase
19.32 ft / 5.89 m
Width Over Tires
18.05 ft / 5.50 m
Engine
Alternator Supplied Amperage
150 A
Bore
5.70 in / 145 mm
Converter Drive - Forward 1
4.40
Converter Drive - Forward 2
7.60
Converter Drive - Forward 3
12.80
Converter Drive - Reverse 1
4.60
Converter Drive - Reverse 2
8.10
Converter Drive - Reverse 3
13.90
Cooling System Fluid Capacity
77 gal / 291.5 L
Direct Drive - Forward 2
8
Direct Drive - Forward 3
14.20
Direct Drive - Reverse 1
4.90
Direct Drive - Reverse 2
8.80
Direct Drive - Reverse 3
15.40
Displacement
9 cu in / 0.1 L
Emissions
U.S. EPA Tier 4 Final
Emissions (Tier 2 Equivalent): Gross Power - Iso 14396
884
Emissions (Tier 2 Equivalent): Gross Power - Sae J1995
907
Emissions (Tier 2 Equivalent): Net Power - Sae J1349
814
Emissions (Tier 2 Equivalent): Net Power - Sae J1995
814
Emissions (Tier 2 Equivalent): Peak Torque At 1,200 Rpm - Sae J1995
4796
Emissions (Tier 2 Equivalent): Rated Speed
1750
Emissions (U.S. Epa Tier 4 Final): Gross Power - Iso 14396
884
Emissions (U.S. Epa Tier 4 Final): Gross Power - Sae J1995
900
Emissions (U.S. Epa Tier 4 Final): Net Power - Sae J1349
814
Emissions (U.S. Epa Tier 4 Final): Net Power - Sae J1995
814
Emissions (U.S. Epa Tier 4 Final): Peak Torque At 1,200 Rpm - Sae J1995
4765
Emissions (U.S. Epa Tier 4 Final): Rated Speed
1750
Engine Make
2236
Engine Model
C32 ACERT
Engine Oil Fluid Capacity
32 gal / 121.1 L
Forward - 1
4.30 mph / 6.9 km/h
Forward - 2
7.40 mph / 11.9 km/h
Forward - 3
12.60 mph / 20.3 km/h
Front Axle/Diff Fluid Capacity
95 gal / 359.6 L
Fuel Capacity
413 gal / 1,563.4 L
Fuel Tank
413 gal / 1,563.4 L
Gross Power
904 hp / 674.1 kW
Gross Power - Sae J1995
904 hp / 674.1 kW
Gross Power***
900 hp / 671.1 kW
Lift Cylinder - Stroke
45.20 in / 1,148 mm
Lock-up disabled
1
Max Speed - Forward
12.80 mph / 20.6 km/h
Max Speed - Reverse
13.90 mph / 22.4 km/h
Net Power
801 hp / 597.3 kW
Net Power***
814 hp / 607.0 kW
Number of Cylinders
12
Number of Forward Gears
3
Number of Reverse Gears
3
Operating Voltage
24 V
Operating Weight
214,948 lb / 97,499 kg
Operating Weight - High Lift
226,249 lb / 102,625 kg
Operating Weight - High Lift**
221,847 lb / 100,628 kg
Operating Weight - Standard
220,089 lb / 99,831 kg
Operating Weight - Standard Lift
214,948 lb / 97,499 kg
Operating Weight - Standard Lift*
220,089 lb / 99,831 kg
Power Measured @
1,750 rpm
Rear Axle/Diff Fluid Capacity
91 gal / 344.5 L
Reverse - 1
4.70 mph / 7.6 km/h
Reverse - 2
8.10 mph / 13.0 km/h
Reverse - 3
13.80 mph / 22.2 km/h
Static Tipping Weight
113,450 lb / 51,460 kg
Stroke
6.40 in / 163 mm
Tire Size
45 in / 1,143 mm
Transmission Fluid Capacity
45 gal / 170.3 L
U.S. EPA Tier 4 Final
1,995
Hydraulics
Relief Valve Setting
4,500 psi / 310.3 bar
Other
Rated Payload - High Lift
42,000 lb / 19,051 kg
Rated Payload - High Lift (Face Material)
46,297 lb / 21,000 kg
Rated Payload - Standard (Face Material)
52,911 lb / 24,000 kg
Rated Payload - Standard Lift
48,000 lb / 21,772 kg
Ac Oil
0.10 gal / 0.4 L
Ac Refrigerant
6
B-Pin Height - Maximum Lift
24.60 ft / 7.50 m
Brakes
Meets SAE J1473, OCT90 and ISO 3450:1992
Bucket Capacity - Heaped
15 yd³ / 11.47 m³
Clearance At 45 Degrees Dump (Tooth Tip)
15.10 ft / 4.60 m
Clearance At 50 Degrees Dump (Tooth Tip)
14.70 ft / 4.48 m
Cooling System
77 gal / 291.5 L
Cooling Systems
77 gal / 291.5 L
Crankcase
32 gal / 121.1 L
Differential - Final Drives - Front
95
Differential - Final Drives - Rear
91
Dump*
1.80
Engine Crankcase
32 gal / 121.1 L
Fuel Tank - Standard
413 gal / 1,563.4 L
Gross Power
880 hp / 656.2 kW
Ground To Bumper Clearance
3.90 ft / 1.19 m
Ground To Center Of Axles
5 lb / 2 kg
Ground To Lower Hitch Clearance
2.30 ft / 0.70 m
Ground To Top Of Exhaust Stacks
17.30
Ground To Top Of Hood
13.30
Ground To Top Of Rops
18.70
High Lift Breakout Force
127,775 lb / 57,958 kg
Hydraulic System - Implement
86
Hydraulic System - Steering
42
Hydraulic Tank - Implement
86 gal / 325.5 L
Hydraulic Tank - Steering/Brake
42 gal / 159.0 L
Lift Cylinder - Bore
11 in / 279 mm
Lift Cylinder, Double Acting - Bore
11 in / 279 mm
Lift Cylinder, Double Acting - Stroke
45.20 in / 1,148 mm
Lower Float Down
3.70
Maximum Flow At 1,350 Rpm
95 gal/min / 359.6 L/min
Maximum Flow At 1,850 Rpm
254 gal/min / 961.5 L/min
Maximum Overall Height - Bucket Raised
33.10 ft / 10.09 m
Maximum Overall Length
52.90 in / 1,344 mm
Operating Specifications - High Lift
35
Operating Specifications - Standard Lift
35
Rack Back
4.40
Raise
9.40
Raise*
9.40
Reach - Maximum Lift
6.90 ft / 2.10 m
Rear Axle - Centerline To Bumper
14 lb / 6 kg
Relief Valve Setting - Lift/Tilt
4,500 psi / 310.3 bar
Relief Valve Setting - Low Idle
4,500 psi / 310.3 bar
Serial Number Prefix
880
Standard Lift Breakout Force
128,895 lb / 58,466 kg
Static Tipping Load - At 35 Degrees Articulation
114,760 lb / 52,054 kg
Steering Cut Off Pressure
4,500 psi / 310.3 bar
Steering Cycle Times - High Idle
4.40
Steering Cycle Times - Low Idle
6.40
Tilt Cylinder - Bore
10.50 in / 267 mm
Tilt Cylinder - Stroke
80.90 in / 2,055 mm
Tilt Cylinder, Double Acting - Bore
10.50 in / 267 mm
Tilt Cylinder, Double Acting - Stroke
80.90 in / 2,055 mm
Total Hydraulic Cycle Time
14.90
Transmission
45
Windshield Washer Fluid
4.90
