Overview
The Volvo Construction Equipment Volvo A40D is a articulated dump truck listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 420 hp, capacity of 29.3 yd3, travel speed of 34.8 mph, fuel capacity of 126.9 gal and hydraulic capacity of 66.1 gal. This model can be reviewed for equipment comparison, jobsite planning, fleet research, and specification-based machine selection. Use the full specifications table to compare the Volvo Construction Equipment Volvo A40D against similar articulated dump truck models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Net Power
420
hp
Gross Power
426
hp
Rated Payload
81,571.04
lb
Overall Length
37.04
ft
Full Specifications
35 specs
Dimensions
Capacity - Heaped
29.43 yd³ / 22.50 m³
Capacity - Struck
22.11 yd³ / 16.90 m³
Dump Angle
70 deg
Dump Ground Clearance
2.98 ft / 0.91 m
Dump Height
24.23 ft / 7.39 m
Ground Clearance
2.03 ft / 0.62 m
Overall Height
12.29 ft / 3.75 m
Overall Length
37.04 ft / 11.29 m
Overall Width
10.73 ft / 3.27 m
Rated Payload
81,571 lb / 37,000 kg
Wheelbase
14.60 ft / 4.45 m
Engine
Alternator Supplied Amperage
55 A
Capacity - Heaped
29.30 yd³ / 22.40 m³
Cooling System Fluid Capacity
31 gal / 117.3 L
Displacement
732 cu in / 12.0 L
Engine Make
2244
Engine Model
D12C AAE2*
Engine Oil Capacity
13.30 gal / 50.3 L
Front Axle - Empty
35,935 lb / 16,300 kg
Front Axle - Loaded
42,263 lb / 19,170 kg
Fuel Capacity
126.90 gal / 480.4 L
Gross Power
426 hp / 317.7 kW
Hydraulic System Fluid Capacity
66.10 gal / 250.2 L
Max Speed
34.80 mph / 56.0 km/h
Max Torque
1,517 lb-ft / 2,056 Nm
Net Power
420 hp / 313.2 kW
Number of Forward Gears
6
Number of Reverse Gears
2
Operating Voltage
24 V
Rear Axle - Empty
33,003 lb / 14,970 kg
Rear Axle - Loaded
108,247 lb / 49,100 kg
Total Empty
68,939 lb / 31,270 kg
Total Loaded
150,510 lb / 68,270 kg
Transmission Fluid Capacity
12.90 gal / 48.8 L
Hydraulics
Lower Time
10 sec
Videos 3
Related Machines
Related Guides & Articles
Frequently Asked Questions
How powerful is the Volvo Construction Equipment Volvo A40D engine? +
The Volvo Construction Equipment Volvo A40D produces 426 hp (317.7 kW) of engine power. This output is typical for its weight class and designed to handle demanding Articulated Dump Truck work cycles efficiently.
How does the Volvo Construction Equipment Volvo A40D compare to similar Articulated Dump Truck models? +
You can compare the Volvo Construction Equipment Volvo A40D side by side with any other model using the Heavy Equipment Hub compare tool. Key comparison points include engine power, operating weight, digging depth, hydraulic flow, and overall dimensions.
