Bobcat T76-2 Compact Track Loader
Bobcat T76-2 compact track loader specs: 74 hp, 9,592 lb operating weight, 2,900 lb rated operating capacity with solid undercarriage, 30.3 gpm high-flow hydraulics, and 31.7 gal fuel capacity.
Quick answer
Bobcat T76-2 Compact Track Loader Specs at a Glance
The Bobcat T76-2 Compact Track Loader is a 9,592 lb compact track loader rated at 74 net horsepower with a listed bucket capacity of 0.75 cu yd. Use this page to check the core model specs, then confirm the exact serial range, blade or bucket, undercarriage, counterweight, hydraulic options, and emissions package before using the numbers for purchase, transport, or bid decisions.
Spec basis: T76-2 compact track loader public North America product/specification reference. Confirm exact market, serial range, track width, bucket, counterweight, hydraulic package, emissions package, and attachments before using values for transport, bidding, purchase, rental, or service planning.
Research Path
Next Steps for T76-2
Key OEM Spec Summary
Fuel burn and hourly operating cost are Heavy Equipment Hub editorial planning estimates. They are not OEM guaranteed values.
Complete OEM Technical Data Sheet
Verified OEM engine parameters, hydraulic pressure circuits, digging forces, and transport dimensions.
| Reference Name | Bobcat T76-2 Compact Track Loader product specifications |
| Primary OEM Reference | https://www.bobcat.com/na/en/equipment/loaders/compact-track-loaders/t76-2 |
| Last Reviewed | September 2026 |
| Spec Configuration | T76-2 compact track loader public North America product/specification reference. Confirm exact market, serial range, track width, bucket, counterweight, hydraulic package, emissions package, and attachments before using values for transport, bidding, purchase, rental, or service planning. |
| Cost and Fuel Note | Fuel burn and hourly operating cost are Heavy Equipment Hub editorial planning estimates. They are not OEM guaranteed values. |
| Editorial Guardrail | Bobcat data is published as a source-checked model page with configuration notes. Deeper compact track loader cluster guides should be added one search intent at a time. |
| Horsepower | 74 hp |
| Hydraulic Horsepower - Standard Flow | 47.6 hp |
| Hydraulic Horsepower - High Flow | 61.9 hp |
| High Idle | 2,600 rpm |
| Low Idle | 1,050 rpm |
| Battery | 1,000A cold cranking amp class |
| Emissions Tier | Tier 4 Final |
| Operating Weight | 9,592 lb |
| Rated Operating Capacity - Solid Undercarriage | 2,900 lb |
| Rated Operating Capacity - Torsion Suspension | 2,800 lb |
| Rated Operating Capacity - 200 lb Counterweight | 3,025 lb |
| Rated Operating Capacity - 300 lb Counterweight | 3,100 lb |
| Tipping Load | 8,285 lb |
| Travel Speed - Low | 6.8 mph |
| Travel Speed - High | 9.2 mph |
| Ground Pressure | 5.8 psi |
| Auxiliary Standard Flow | 23.3 gpm |
| Auxiliary High Flow | 30.3 gpm |
| Auxiliary Pressure | 3,500 psi |
| System Relief at Quick Couplers | 3,500 psi |
| Attachment Interface | Bob-Tach style loader attachment system |
| Attachment Planning Note | Confirm high-flow option, case drain, electrical control kit, and coupler style before matching mulchers, cold planers, sweepers, or soil conditioners. |
| Length Without Attachment | 114.0 in |
| Length With Standard Bucket | 142.3 in |
| Width | 73.5 in |
| Height With Operator Cab | 81.9 in |
| Height to Bucket Hinge Pin | 128.3 in |
| Reach at Maximum Height | 36.3 in |
| Turning Radius | 85.3 in |
| Length of Track on Ground | 59.2 in |
| Standard Track Width | 12.6 in |
| Optional Wide Track Width | 17.7 in |
| Fuel Tank Capacity | 31.7 gal |
| Grease Interval | 10 hours |
| Planning Bucket Capacity | 0.75 yd3 editorial planning basis; verify actual bucket model before estimating production |
| Maintenance Planning | Build the 500-hour service plan around engine oil, hydraulic filters, fuel filtration, track inspection, rollers, sprockets, cooling package cleaning, and attachment coupler wear. |
| Best Fit | Owners who need a 74 hp high-lift compact track loader with strong flotation, high-flow attachment potential, and a transport weight under many larger CTL options. |
| Verify Before Transport | Track width, bucket, counterweight, cab package, ballast, attachment, fuel level, and trailer deck width can change the real hauling plan. |
| Used Machine Inspection Focus | Check track wear, roller leaks, sprocket condition, lift-arm pins, quick coupler lockup, auxiliary hydraulic leaks, cab electronics, cooling package cleanliness, and service records. |
| Common Long-Tail Searches Answered | Bobcat T76-2 weight, T76-2 horsepower, Bobcat T76-2 rated operating capacity, T76-2 high flow gpm, T76-2 fuel capacity, Bobcat T76-2 vs T76 specs. |
Machine Architecture & Operational Overview
The Bobcat T76-2 is a vertical-lift compact track loader for grading, site prep, landscape construction, utility cleanup, snow work, pallet handling, and hydraulic attachment jobs where flotation and lift height matter more than excavator-style dig depth. It fits searches from owners comparing the T76-2 against the Cat 259D3, Cat 289D3, Kubota SVL75-3, Takeuchi TL10V2, and John Deere 325G/331 P-Tier class machines. The practical buying questions are rated operating capacity, tipping load, track width, auxiliary flow, fuel tank size, hinge pin height, and whether the selected machine has the standard-flow or high-flow hydraulic package. Bucket capacity below is a planning value for a common dirt or utility bucket, not a universal OEM bucket rating.
Primary Jobsite Applications: Landscape grading, residential site prep, utility cleanup, snow removal, pallet handling, brush cutting, soil conditioning, trench backfill, and compact hydraulic attachment work
Buyer and Fleet Checklist
Before You Use These Specs
Transport Planning
Confirm weight, width, height, bucket or blade removal, counterweight, shoe width, tire package, permits, and trailer capacity against the actual machine configuration.
Attachment Matching
Check hydraulic flow, relief pressure, coupler style, case drain, return filtration, tool control, lifting limits, and dealer-approved attachment charts.
Cost Per Hour
Build the hourly rate from fuel, DEF, preventive maintenance, wear parts, tires or undercarriage, repairs, depreciation, finance cost, insurance, and utilization.
Spec Accuracy
Use the source link and configuration note as the starting point, then verify serial range and local-market literature before purchase, repair, hauling, or bid work.
Common Long-Tail Searches This Page Answers
What is the operating weight?
9,592 lb, depending on configuration.
How much horsepower does it have?
74 net hp for the listed engine configuration.
What blade capacity is listed?
0.75 cu yd for the listed blade configuration.
What should be verified before use?
Serial prefix, attachment package, counterweight, track shoe width, emissions tier, and local dealer documentation.
Bobcat T76-2 Compact Track Loader FAQ
What is the operating weight of the Bobcat T76-2 Compact Track Loader?
The listed operating weight is 9,592 lb for the referenced configuration. Buckets, blades, couplers, thumbs, guards, counterweights, tires, track shoes, fuel level, and regional packages can change the final transport weight.
How much horsepower does the Bobcat T76-2 Compact Track Loader have?
The listed net horsepower is 74 hp. Confirm the exact engine rating standard, emissions package, and model year before using the value for bidding, rental comparison, or attachment sizing.
Is the fuel burn shown here an OEM guaranteed number?
No. The fuel burn and hourly cost values are Heavy Equipment Hub planning estimates. Real fuel use changes with load factor, idle time, operator habits, hydraulic demand, underfoot conditions, maintenance condition, and job cycle.
What should I verify before buying, renting, or transporting this machine?
Verify serial range, configuration, attachment package, fluid specifications, transport dimensions, tire or track setup, counterweight, emissions equipment, service history, and the latest OEM or dealer documentation.
Recommended OEM Filters & Fluid Maintenance Kits
Bobcat 500-Hour Scheduled Maintenance Filter Kit
Official heavy duty hydraulic return filters, engine oil filters, fuel water separators, and SOS fluid sampling bottles.
Bobcat T76-2 Compact Track Loader Knowledge Base & Topic Cluster
Deep-dive technical guides attached to this master machine pillar.
Bobcat T76-2 Operating Cost Per Hour: Fuel, Tracks, High Flow Attachments and Ownership
Estimate Bobcat T76-2 operating cost per hour with fuel burn, rubber tracks, high-flow attachments, undercarriage reserve, idle time, maintenance and ownership.
Fleet Management Specs
Spec Verification
Core machine values are checked against the Bobcat T76-2 Compact Track Loader product specifications. Configuration-sensitive values should still be verified against the exact serial range and dealer spec sheet.
Primary OEM reference
