John Deere 333 P-Tier Compact Track Loader
John Deere 333 P-Tier compact track loader specs: 105.8 hp net power, 12,183 lb operating weight, 3,850 lb rated operating capacity, 44 gpm optional high flow, and 36 gal fuel capacity.
Quick answer
John Deere 333 P-Tier Compact Track Loader Specs at a Glance
The John Deere 333 P-Tier Compact Track Loader is a 12,183 lb compact track loader rated at 106 net horsepower with a listed bucket capacity of 0.85 cu yd. Use this page to check the core model specs, then confirm the exact serial range, blade or bucket, undercarriage, counterweight, hydraulic options, and emissions package before using the numbers for purchase, transport, or bid decisions.
Spec basis: 333 P-Tier compact track loader public North America product/specification reference. Confirm exact market, serial range, track width, bucket, counterweight, hydraulic package, emissions package, and attachments before using values for transport, bidding, purchase, rental, or service planning.
Research Path
Next Steps for 333 P-Tier
Key OEM Spec Summary
Fuel burn and hourly operating cost are Heavy Equipment Hub editorial planning estimates. They are not OEM guaranteed values.
Complete OEM Technical Data Sheet
Verified OEM engine parameters, hydraulic pressure circuits, digging forces, and transport dimensions.
| Reference Name | John Deere 333 P-Tier Compact Track Loader product specifications |
| Primary OEM Reference | https://www-cm-ue.deere.com/en-us/products-solutions/construction-equipment/compact-track-loaders/333-p-tier-compact-track-loader-mdbwmfq |
| Secondary OEM Reference | https://www.deere.ca/en/loaders/compact-track-loaders/333-p-compact-track-loader/ |
| Last Reviewed | September 2026 |
| Spec Configuration | 333 P-Tier compact track loader public North America product/specification reference. Confirm exact market, serial range, track width, bucket, counterweight, hydraulic package, emissions package, and attachments before using values for transport, bidding, purchase, rental, or service planning. |
| Cost and Fuel Note | Fuel burn and hourly operating cost are Heavy Equipment Hub editorial planning estimates. They are not OEM guaranteed values. |
| Editorial Guardrail | John Deere data is published as a source-checked model page with configuration notes. Deeper compact track loader cluster guides should be added one search intent at a time. |
| Engine Make and Model | Yanmar 4TNV94FHT |
| Gross Rated Power | 108.5 hp |
| Net Peak Power | 105.8 hp |
| Rated Speed | 2,500 rpm |
| Peak Torque | 290.6 lb-ft |
| Displacement | 186.33 cu in |
| Cylinders | 4 |
| Aspiration | Turbocharged and intercooled |
| Emissions | Final Tier 4 / EU Stage V |
| Operating Weight | 12,183 lb |
| Rated Operating Capacity | 3,850 lb |
| Tipping Load | 11,000 lb |
| Lift Breakout Force | 8,500 lbf |
| Bucket Breakout Force | 13,750 lbf |
| Maximum Travel Speed | 8.5 mph |
| Ground Bearing Pressure | 4.8 psi |
| Track Shoe Width Reference | 17.7 in reference track package |
| Hydraulic System Type | Pressure-compensating load-sensing hydraulics |
| Pump Flow - Standard | 25 gpm |
| Pump Flow - Optional High Flow | 44 gpm |
| System Pressure | 3,500 psi |
| Hydraulic Power - Standard | 51.1 hp |
| Hydraulic Power - Optional High Flow | 89.9 hp |
| Attachment Planning Note | Confirm high-flow package, electrical controls, coupler, case drain, cooling condition, and dealer attachment chart before pairing high-demand tools. |
| Length Without Bucket | 125.0 in |
| Length With Bucket | 151.2 in |
| Width Without Bucket - 15.8 in Tracks | 78.86 in |
| Width Without Bucket - 17.7 in Tracks | 80.7 in |
| Height to Top of ROPS | 87.4 in |
| Height to Hinge Pin | 132.0 in |
| Dump Height | 106.08 in |
| Ground Clearance | 9.75 in |
| Front Turn Radius | 86.0 in |
| Bucket Rollback at Ground | 35 degrees |
| Dump Angle | 48 degrees |
| Fuel Tank Capacity | 36 gal |
| Cold Cranking Amps | 950 CCA |
| Electrical System Voltage | 12 V |
| Alternator Output with A/C | 120 amp |
| Planning Bucket Capacity | 0.85 yd3 editorial planning basis; verify actual bucket model before estimating production |
| Best Fit | Fleets needing a large-frame CTL for high-flow attachments, higher rated operating capacity, and stronger breakout force than mid-frame compact loaders. |
| Verify Before Transport | Track package, bucket, attachment, cab, counterweight, ballast, fuel level, and guarding affect real hauling weight and width. |
| Used Machine Inspection Focus | Inspect tracks, rollers, sprockets, final drives, lift-arm pins, high-flow hydraulic heat history, coupler lockup, DEF/emissions history, electrical controls, and service documentation. |
| Common Long-Tail Searches Answered | John Deere 333 P-Tier weight, 333 P-Tier horsepower, Deere 333 P rated operating capacity, Deere 333 P high flow gpm, John Deere 333 P fuel capacity, 333 P-Tier vs 333G specs. |
Machine Architecture & Operational Overview
The John Deere 333 P-Tier is a large-frame compact track loader for contractors who want CTL flotation with high horsepower, strong breakout force, and enough hydraulic capacity for demanding attachments. It is a high-intent comparison machine for land clearing, grading, utility work, snow support, recycling yards, material handling, and attachment-heavy rental fleets. Buyers usually compare it with the Cat 299D3 XE, Takeuchi TL12V2, Kubota SVL97-2, Bobcat T86, and Case TV620B, but the real decision depends on rated operating capacity, optional high-flow hydraulics, track width, ground pressure, attachment control package, dealer support, and actual transport weight. Bucket capacity below is an editorial planning value; verify the exact Deere bucket or attachment before quoting production.
Primary Jobsite Applications: High-flow attachment work, brush cutting, cold planing, grading, snow removal, utility cleanup, material handling, site prep, and large-frame CTL rental fleet work
Buyer and Fleet Checklist
Before You Use These Specs
Transport Planning
Confirm weight, width, height, bucket or blade removal, counterweight, shoe width, tire package, permits, and trailer capacity against the actual machine configuration.
Attachment Matching
Check hydraulic flow, relief pressure, coupler style, case drain, return filtration, tool control, lifting limits, and dealer-approved attachment charts.
Cost Per Hour
Build the hourly rate from fuel, DEF, preventive maintenance, wear parts, tires or undercarriage, repairs, depreciation, finance cost, insurance, and utilization.
Spec Accuracy
Use the source link and configuration note as the starting point, then verify serial range and local-market literature before purchase, repair, hauling, or bid work.
Common Long-Tail Searches This Page Answers
What is the operating weight?
12,183 lb, depending on configuration.
How much horsepower does it have?
106 net hp for the listed engine configuration.
What blade capacity is listed?
0.85 cu yd for the listed blade configuration.
What should be verified before use?
Serial prefix, attachment package, counterweight, track shoe width, emissions tier, and local dealer documentation.
John Deere 333 P-Tier Compact Track Loader FAQ
What is the operating weight of the John Deere 333 P-Tier Compact Track Loader?
The listed operating weight is 12,183 lb for the referenced configuration. Buckets, blades, couplers, thumbs, guards, counterweights, tires, track shoes, fuel level, and regional packages can change the final transport weight.
How much horsepower does the John Deere 333 P-Tier Compact Track Loader have?
The listed net horsepower is 106 hp. Confirm the exact engine rating standard, emissions package, and model year before using the value for bidding, rental comparison, or attachment sizing.
Is the fuel burn shown here an OEM guaranteed number?
No. The fuel burn and hourly cost values are Heavy Equipment Hub planning estimates. Real fuel use changes with load factor, idle time, operator habits, hydraulic demand, underfoot conditions, maintenance condition, and job cycle.
What should I verify before buying, renting, or transporting this machine?
Verify serial range, configuration, attachment package, fluid specifications, transport dimensions, tire or track setup, counterweight, emissions equipment, service history, and the latest OEM or dealer documentation.
