Overview
The Caterpillar 992C is a wheel loader listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 690 hp, operating weight of 187,790 lb, fuel capacity of 300.1 gal and hydraulic capacity of 143.0 gal. This model can be reviewed for loading, stockpile work, material handling, yard operations, and fleet comparison workflows. Use the full specifications table to compare the Caterpillar 992C against similar wheel loader models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Operating Weight
187,789.80
lb
Net Power
690
hp
Bucket Capacity - Heaped
12.60
yd3
Full Specifications
23 specs
Dimensions
Breakout Force
147,050 lb / 66,701 kg
Bucket Capacity - Heaped
12.56 yd³ / 9.60 m³
Bucket Capacity - Struck
10.70 yd³ / 8.18 m³
Bucket Width
15.09 ft / 4.60 m
Dump Clearance At Max Raise
14.76 ft / 4.50 m
Height to Top of Cab
28.68 ft / 8.74 m
Length With Bucket On Ground
41.74 in / 1,060 mm
Reach At Max Lift And Dump
6.84 ft / 2.08 m
Engine
Displacement
1,648 cu in / 27.0 L
Engine Model
3412
Fuel Capacity
300.10 gal / 1,136.0 L
Hydraulic System Fluid Capacity
143 gal / 541.3 L
Max Speed - Forward
13.20 mph / 21.2 km/h
Max Speed - Reverse
14.50 mph / 23.3 km/h
Net Power
690 hp / 514.5 kW
Number of Forward Gears
3
Number of Reverse Gears
3
Operating Weight
187,790 lb / 85,180 kg
Static Tipping Weight
106,483 lb / 48,300 kg
Hydraulics
Bucket Capacity - Heaped
12.60 yd³ / 9.63 m³
Dump Time
2.50 sec
Lower Time
4 sec
Raise Time
12 sec
Videos 6
Related Machines
Related Guides & Articles
Mar 14, 2026
Wheel Loader vs Skid Steer: Which Machine Fits Your Job Best?
Read article →
Mar 17, 2026
Inside the Power of Two Giant Cat 990 Wheel Loaders – Massive Coal Loading Operation
Read article →
Mar 17, 2026
Ultimate Guide to Mega Machines: Excavators, Haulers, Wheel Loaders & Bulldozers in 4K
Read article →
Frequently Asked Questions
What is the operating weight of the Caterpillar 992C? +
The Caterpillar 992C has an operating weight of 187,790 lb (85,180 kg). This places it in a class suited for wheel loader applications where ground pressure and transport weight are key considerations.
How powerful is the Caterpillar 992C engine? +
The Caterpillar 992C produces 690 hp (514.5 kW) of engine power. This output is typical for its weight class and designed to handle demanding Wheel Loader work cycles efficiently.
How does the Caterpillar 992C compare to similar Wheel Loader models? +
You can compare the Caterpillar 992C side by side with any other model using the Heavy Equipment Hub compare tool. Key comparison points include engine power, operating weight, digging depth, hydraulic flow, and overall dimensions.
