Dimensions
Boom/Stick Option (Hex) 1
Boom 6500mm (21\' 4\'\') / Stick 12\' 10\'\'
Counterweight Clearance
48.03 ft / 14.64 m
Ground Clearance
1.48 ft / 0.45 m
Height to Top of Cab
10.31 ft / 3.14 m
Length of Track on Ground
13.26 ft / 4.04 m
Max Cutting Height
35.27 ft / 10.75 m
Max Digging Depth
26.86 ft / 8.19 m
Max Loading Height
24.75 ft / 7.54 m
Max Reach Along Ground
38.44 ft / 11.72 m
Max Vertical Wall Digging Depth
23.47 ft / 7.15 m
Removal Counterweight Clearance
4 lb / 2 kg
Shipping Height
1 ft / 0.30 m
Shipping Height Of Unit
11.91 ft / 3.63 m
Shipping Length Of Unit
36.75 ft / 11.20 m
Tail Swing Radius
11.49 ft / 3.50 m
Transport Width
133.50 in / 3,391 mm
Width To Outside Of Tracks
11.13 ft / 3.39 m
Engine
Bore
5.90 in / 150 mm
Cooling System Fluid Capacity
10.60 gal / 40.1 L
Counterweight
13,272 lb / 6,020 kg
Displacement
537 cu in / 8.8 L
Engine Make
2236
Engine Model
C9
Engine Oil Capacity
10.60 gal / 40.1 L
Fuel Capacity
163.80 gal / 620.1 L
Fuel Tank Capacity
163.80 gal / 620.1 L
Hydraulic Pump Flow Capacity
74 gal/min / 280.1 L/min
Hydraulic System Fluid Capacity
108.40 gal / 410.3 L
Hydraulic System Relief Valve Pressure
5,076 psi / 350.0 bar
Hydraulic Tank
46.20 gal / 174.9 L
Maximum Bucket Capacity
3.40 yd³ / 2.60 m³
Maximum Operating Weight
82,962 lb / 37,631 kg
Minimum Bucket Capacity
1.30 yd³ / 0.99 m³
Minimum Operating Weight
78,634 lb / 35,668 kg
Net Flywheel Power
268 hp / 199.8 kW
Net Power
266 hp / 198.4 kW
Net Power - Eec 80/1269
268 hp / 199.8 kW
Net Power - Iso 9249
268 hp / 199.8 kW
Net Power - Sae J1349
266 hp / 198.4 kW
Operating Weight
67,237 lb / 30,498 kg
Reference Bucket Capacity
1.60 yd³ / 1.22 m³
Swing Drive
5 deg
Swing Drive Fluid Capacity
5.10 gal / 19.3 L
Swing Speed
10 deg
Swing Torque
80,142 deg
Hydraulics
Boom Cylinder - Bore
5.90 in / 150 mm
Boom Cylinder - Stroke
56.70 in / 1,440 mm
Db Family Bucket Cylinder - Stroke
45.30 in / 1,151 mm
Engine Oil
10.60 gal / 40.1 L
Main Implement System - Maximum Flow (2x)
74 gal/min / 280.1 L/min
Maximum Pressure - Equipment - Heavy Lift
5,221 psi / 360.0 bar
Maximum Pressure - Equipment - Normal
5,076 psi / 350.0 bar
Maximum Pressure - Swing
4,061 psi / 280.0 bar
Maximum Pressure - Travel
5,076 psi / 350.0 bar
Performance
ANSI/SAE J1166 OCT 98
Pilot System - Maximum Flow
11.40 gal/min / 43.2 L/min
Pilot System - Maximum Pressure
566 psi / 39.0 bar
Stick Cylinder - Bore
6.70 in / 170 mm
Stick Cylinder - Stroke
68.40 in / 1,737 mm
Tb Family Bucket Cylinder - Bore
6.30 in / 160 mm
Tb Family Bucket Cylinder - Stroke
53.40 in / 1,356 mm
Other
Brakes
SAE J1026 APR90
Cab/Fogs
1,356
Cooling System
10.60 gal / 40.1 L
Final Drive - Each
2.1
Hydraulic System - Including Tank
108.30 gal / 410.0 L
Maximum Drawbar Pull
67,443 lb / 30,592 kg
Maximum Travel Speed
3.10 mph / 5.0 km/h
Net Power
255 hp / 190.2 kW
Number Of Carrier Rollers - Each Side - Long Undercarriage
2
Number Of Shoes - Each Side - Long Undercarriage
49
Number Of Track Rollers - Each Side - Long Undercarriage
9
Optional - Double Grouser
28
Standard With Long Undercarriage
32
Undercarriage
Drawbar Pull
67,443 lb / 30,591 kg
Max Travel Speed
3.11 mph / 5.0 km/h
Shoe Size
31.50 in / 800 mm
Track Gauge
8.50 ft / 2.59 m
