Overview
The Caterpillar D6R LGP Series II is a crawler tractor listed in the Heavy Equipment Hub equipment database with structured specifications for comparison, research, and machine selection. Key specification points include engine power of 185 hp, operating weight of 45,086 lb, working depth of 25.80 ft and fuel capacity of 101.0 gal. This model can be reviewed for pulling power, implement matching, agricultural operations, and equipment comparison. Use the full specifications table to compare the Caterpillar D6R LGP Series II against similar crawler tractor models by power, weight, capacity, dimensions, speed, and other technical values.
Key Specifications
Operating Weight
45,086
lb
Gross Power
185
hp
Full Specifications
27 specs
Dimensions
Ground Clearance
1.43 ft / 0.44 m
Height to Top of Cab
10.67 ft / 3.25 m
Length of Track on Ground
10.67 ft / 3.25 m
Length w/ Blade
17.92 ft / 5.46 m
Length w/o Blade
13.92 ft / 4.24 m
Width Over Tracks
10.31 ft / 3.14 m
Engine
Displacement
537 cu in / 8.8 L
Engine Make
2236
Engine Model
C9
Fuel Capacity
101 gal / 382.3 L
Gross Power
185 hp / 138.0 kW
Height
43.40 in / 1,102 mm
Max Speed - Forward
7.70 mph / 12.4 km/h
Max Speed - Reverse
10 mph / 16.1 km/h
Number of Cylinders
6
Number of Forward Gears
3
Number of Reverse Gears
3
Operating Weight
45,086 lb / 20,451 kg
Power Measured @
2,000 rpm
Width
13.10 ft / 3.99 m
Hydraulics
Capacity
4.90 yd³ / 3.75 m³
Cutting Depth
25.80 ft / 7.86 m
Undercarriage
Ground Contact Area
9,254 in² / 59,703.1 cm²
Ground Pressure
5 psi / 0.3 bar
Number of Track Rollers per Side
8
Standard Shoe Size
36.03 in / 915 mm
Track Gauge
7.32 ft / 2.23 m
Videos 1
Frequently Asked Questions
What is the operating weight of the Caterpillar D6R LGP Series II? +
The Caterpillar D6R LGP Series II has an operating weight of 45,086 lb (20,451 kg). This places it in a class suited for crawler tractor applications where ground pressure and transport weight are key considerations.
How powerful is the Caterpillar D6R LGP Series II engine? +
The Caterpillar D6R LGP Series II produces 185 hp (138.0 kW) of engine power. This output is typical for its weight class and designed to handle demanding Crawler Tractor work cycles efficiently.
How does the Caterpillar D6R LGP Series II compare to similar Crawler Tractor models? +
You can compare the Caterpillar D6R LGP Series II side by side with any other model using the Heavy Equipment Hub compare tool. Key comparison points include engine power, operating weight, digging depth, hydraulic flow, and overall dimensions.
